Description
Engine
Model: 4TNV98-ZCNRC2C
Type: WATER-COOLED 4-STROKE 4-CYLINDER VERTICAL DIESEL ENGINE
Displacement (L): 3,318
Output KW(PS): 51.5(70)
Rated speed rpm: 2500
Fuel (L): 67 (diesel)
Starter: Starter Motor
Dimensions
Overall length (mm): 4290
Overall Width (mm): 1940
Overall Height (mm): 2410
Weight (kg): 2915
| Traveling |
Crawler |
Width X Length (mm) |
450 X 1480 |
| Center Distance (mm) |
980 |
| Ground Contact Length (mm) |
170 |
| Change Speed method |
HST, SIDE CLUTCH (HYDRAULIC) |
| Number of shift steps |
3 Steps |
| Travel Speed (m/s) |
Forward (m/s) |
Reverse(m/s) |
| Low |
0 – 1.01 |
0 – 0.83 |
| Standard |
0 – 1.65 |
0 – 1.35 |
| Travel |
0 – 2.05 |
0 – 1.68 |
| Reaping unit |
Reaping Width (mm) |
1400 |
| Reaping lift method |
HYDRAULIC SINGLE LEVER |
| Pick-up speed change |
LOW, STANDARD, HIGH |
| Ear convey |
RIGHT/LEFT CONVEYANCE DEVICE |
| Threshing depthadjust type |
Electric |
| Threshing unit |
Threshing drum |
Diameter x length (mm) |
420 x 910 |
| Rotating Speed (rpm) |
520 |
| Processing Drum |
Diameter x length (mm) |
140 x 900 |
| rotating speed (rpm) |
1722 |
| Sorting Unit |
Width x Length (mm) |
670 x 1540 |
| Sorting System |
Swing, Winnower, Fan-suction |
| Number of outlet/discharge method |
2 / Manual |
| Others |
Warning Device |
Water Temperature, Hydraulic, Fuel, Charge |
| Automatic device |
Thresh Depth automatic control |
| Safety Device |
REAPING BLOCK, SECOND WARNING,FULL PADDY, OBLIQUITY WARNING |
| Adapter Crop Length (cm) |
70 x 120 |
| Grain tank capacity (L) |
1000 |
